品中心/PCB鎖螺絲/DAHM500-15564697156.jpg)
Technical data 技術數據 ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? Approval ?cULus ?VDE | |||
| Technical data(UL/cUL) UL認證數據(UL/cUL)? ? ? ? Use Group應用組別 | B | C | D |
| Nominal voltage (V) 額定電壓(V) | 300 | - | 300 |
| Nominal current (A) 額定電流(A) | 16 | - | 10 |
| Connection capacity(AWG) 接線容量(AWG) | 26-14 | - | 26-14 |
| Technical data in accordance with IEC and VDE ?技術數據，符合IEC/DIN VDE標準 | |||
| Rated insulation voltage at pollution degree 2(V)額定電壓/污染等級2 | 250 | ||
| Rated current/conductor cross-section (A/mm2) 額定電流/接線容量 | 17.5/2.5 | ||
| Solid/stranded(mm2) 單芯線（剛性）/多芯線（柔性） | 0.5-2.5/0.5-2.5 | ||
| Surge voltage category/pollution degree 浪涌電壓類別/污染等級 | III/3 | III/2 | II/2 |
| Rated insulation voltage(V) 額定電壓 | 250 | 320 | 630 |
| Rated surge voltage(kV) 額定浪涌電壓 | 4 | 4 | 4 |
| Genenral data ?一般參數 | |||
| Stripping length(mm) 剝線長度 | 6-7 | ||
| Screw thread 螺紋規格 | M3 | ||
| Tightening torque(Nm) 最大緊固扭矩 | 0.4 | ||
| Insulation material group 絕緣材料類型/材料組別 | PA66/I | ||
| Inflammblility class acc. to UL94 阻燃等級，符合UL94標準 | V0 | ||
