Technical data 技術數據 Approval cULus VDE | |||
| Technical data(UL/cUL) UL認證數據(UL/cUL) Use Group應用組別 | B | C | D |
| Nominal voltage (V) 額定電壓(V) | 300 | 50 | 300 |
| Nominal current (A) 額定電流(A) | 8 | 8 | 8 |
| Connection capacity(AWG) 接線容量(AWG) | - | - | - |
| Technical data in accordance with IEC and VDE 技術數據，符合IEC/DIN VDE標準 | |||
| Rated insulation voltage at pollution degree 2(V)額定電壓/污染等級2 | 160 | ||
| Rated current/conductor cross-section (A/mm2) 額定電流/接線容量 | 8/- | ||
| Solid/stranded(mm2) 單芯線（剛性）/多芯線（柔性） | - | ||
| Surge voltage category/pollution degree 浪涌電壓類別/污染等級 | III/3 | III/2 | II/2 |
| Rated insulation voltage(V) 額定電壓 | 160 | 160 | 250 |
| Rated surge voltage(kV) 額定浪涌電壓 | 2.5 | 2.5 | 2.5 |
| Genenral data 一般參數 | |||
| Screw Nut tightening torque(N.m) 法蘭螺母緊固扭力 | - | ||
| Flange Nut thread 法蘭螺紋規格 | - | ||
| Insulation material group 絕緣材料類型/材料組別 | LCP/I | ||
| Inflammblility class acc. to UL94 阻燃等級，符合UL94標準 | V0 | ||
| Borehole diameter/pin dimensions PCB鉆孔尺寸/針腳尺寸 | 1.4/0.8*0.8 | ||
