Technical data 技術數據 Approval cULus VDE | |||
Technical data(UL/cUL) UL認證數據(UL/cUL) Use Group應用組別 | B | C | D |
Nominal voltage (V) 額定電壓(V) | 300 | - | 300 |
Nominal current (A) 額定電流(A) | 7 | - | 7 |
Connection capacity(AWG) 接線容量(AWG) | 24-18 | - | 24-18 |
Technical data in accordance with IEC and VDE 技術數據,符合IEC/DIN VDE標準 | |||
Rated insulation voltage at pollution degree 2(V)額定電壓/污染等級2 | 320 | ||
Rated current/conductor cross-section (A/mm2) 額定電流/接線容量 | 8/1.5 | ||
Solid/stranded(mm2) 單芯線(剛性)/多芯線(柔性) | 0.2-1.5/0.2-1.5 | ||
Surge voltage category/pollution degree 浪涌電壓類別/污染等級 | III/3 | III/2 | II/2 |
Rated insulation voltage(V) 額定電壓 | 250 | 320 | 630 |
Rated surge voltage(kV) 額定浪涌電壓 | 4 | 4 | 4 |
Genenral data 一般參數 | |||
Stripping length(mm) 剝線長度 | 7-8 | ||
Screw flange tightening torque(N.m) 法蘭螺絲緊固扭力 | - | ||
Flange Screw thread 法蘭螺紋規格 | - | ||
Insulation material group 絕緣材料類型/材料組別 | PA66/I | ||
Inflammblility class acc. to UL94 阻燃等級,符合UL94標準 | V0 |
