Technical data 技術數據 Approval cULus VDE | |||
| Technical data(UL/cUL) UL認證數據(UL/cUL) Use Group應用組別 | B | C | D |
| Nominal voltage (V) 額定電壓(V) | 300 | 50 | 300 |
| Nominal current (A) 額定電流(A) | 8 | 8 | 8 |
| Connection capacity(AWG) 接線容量(AWG) | 24-16 | 24-16 | 24-16 |
| Technical data in accordance with IEC and VDE 技術數據，符合IEC/DIN VDE標準 | |||
| Rated insulation voltage at pollution degree 2(V)額定電壓/污染等級2 | 160 | ||
| Rated current/conductor cross-section (A/mm2) 額定電流/接線容量 | 8/1.5 | ||
| Solid/stranded(mm2) 單芯線（剛性）/多芯線（柔性） | 0.2-1.5/0.2-1.5 | ||
| Surge voltage category/pollution degree 浪涌電壓類別/污染等級 | III/3 | III/2 | II/2 |
| Rated insulation voltage(V) 額定電壓 | 160 | 160 | 250 |
| Rated surge voltage(kV) 額定浪涌電壓 | 2.5 | 2.5 | 2.5 |
| Genenral data 一般參數 | |||
| Stripping length(mm) 剝線長度 | 9-10 | ||
| Screw flange tightening torque(N.m) 法蘭螺絲緊固扭力 | - | ||
| Flange Screw thread 螺紋規格 | M2.5 | ||
| Insulation material group 絕緣材料類型/材料組別 | PA66/I | ||
| Inflammblility class acc. to UL94 阻燃等級，符合UL94標準 | V0 | ||
